Link aggregation (LACP) support between both network ports for redundancy and increased capacity.2.5Gbps speed complies with NBase-T and 802.3bz specifications.E0: HPE SmartRate port (RJ-45, maximum negotiated speed 2.5Gbps).Combining the patterns of each of the antennas of the MIMO radios, the peak gain of the effective per-antenna pattern is 3.8dBi in 2.4GHz and 4.6dBi in 5GHz.The downtilt angle for maximum gain is roughly 30 degrees. Built-in antennas are optimized for horizontal ceiling mounted orientation of the AP. Four integrated dual-band downtilt omni-directional antennas for 4x4 MIMO with peak antenna gain of 4.2dBi in 2.4GHz and 7.5dBi in 5GHz.
Worst-case internal loss between radio interface and external antenna connectors (due to diplexing circuitry): 1.3dB in 2.4GHz and 1.7dB in 5GHz. Four RP-SMA connectors for external dual band antennas (A0 through A3, corresponding with radio chains 0 through 3).802.11ax Target Wait Time (TWT) to support low-power client devicesġ Ignoring the impact of proprietary data rate extensions and OFDMA resource units.Transmit beam-forming (TxBF) for increased signal reliability and range.Low-density parity check (LDPC) for high-efficiency error correction and increased throughput.Space-time block coding (STBC) for increased range and improved reception.Cyclic delay/shift diversity (CDD/CSD) for improved downlink RF performance.Maximum ratio combining (MRC) for improved receiver performance.Advanced Cellular Coexistence (ACC) minimizes the impact of interference from cellular networks.For total (EIRP) transmit power, add antenna gain. Note: conducted transmit power levels exclude antenna gain.2.4 GHz band: +21 dBm (18dBm per chain).Maximum (aggregate, conducted total) transmit power (limited by local regulatory requirements):.Transmit power: Configurable in increments of 0.5 dBm.802.11n/ac packet aggregation: A-MPDU, A-MSDU.802.11ax: Orthogonal frequency-division multiple access (OFDMA) with up to 16 resource units (for an 80MHz channel).802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM).802.11b: Direct-sequence spread-spectrum (DSSS).Including Zero-Wait DFS (ZWDFS) to accelerate channel changes.Dynamic frequency selection (DFS) optimizes the use of available RF spectrum.Available channels: Dependent on configured regulatory domain.
Supported frequency bands (country-specific restrictions apply):.Support for up to 512 associated client devices per radio, and up to 16 BSSIDs per radio.Two spatial stream Single User (SU) MIMO for up to 287Mbps wireless data rate to individual 2SS HE20 802.11ax client devices or to two 1SS HE20 802.11ax DL-MU-MIMO capable client devices simultaneously (typical).Two spatial stream Single User (SU) MIMO for up to 574Mbps wireless data rate to individual 2SS HE40 802.11ax client devices or to two 1SS HE40 802.11ax DL-MU-MIMO capable client devices simultaneously (max).Four spatial stream Multi User (MU) MIMO for up to 2.4Gbps wireless data rate to up to four 1SS or two 2SS HE80 802.11ax DL-MU-MIMO capable client devices simultaneously (typical).Four spatial stream Multi User (MU) MIMO for up to 4.8Gbps wireless data rate to up to four 1SS or two 2SS HE160 802.11ax DL-MU-MIMO capable client devices simultaneously (max).Two spatial stream Single User (SU) MIMO for up to 1.2Gbps wireless data rate to individual 2SS HE80 802.11ax client devices (typical).
